All-flash NASbook, thin & portable Supports 4x M.2 2280 NVMe SSDs 2x 2.5GbE, 2x HDMI™, 2x USB 3.2 Gen 1 (5Gbps) ports
Say goodbye to your external hard drives, and hello NASbook. QNAP’s portable, high-performance TBS-464 NASbook is specifically designed for mobile workers and remote content creators to easily store and share precious business data and content. Let TBS-464 bring you a brand-new business data collaboration experiences of high-speed file transmission, smart storage, and hybrid cloud.
The TBS-464 uses the QTS operating system by default. You will be able to switch to using the QuTS hero operating system. QuTS hero provides benefits such as ZFS data integrity and WORM technology to prevent data tampering. (Switching to QuTS hero is supported starting from QTS 5.2.2.)
-
Quad-core multitasking
Powered by an Intel® Celeron® N5105 quad-core processor, burst up to 2.9 GHz.
-
Thin, portable
The thin and B5-sized TBS-464 weighs just 740 g, while offering storage capacity up to four M.2 2280 NVMe SSDs.
-
4K HDMI™ output
Up to two HDMI™ 2.0 ports support 4K @60Hz output.
-
Record online meetings
Use the TBS-464 with QNAP KoiMeeter to build a high-quality wireless presentation and online video conferencing storage system.
-
Faster USB transfer
Two USB 3.2 Gen 1 (5Gbps) ports allow faster backup to/from USB devices.
Specification
| CPU | Intel® Celeron® N5105 4-core/4-thread processor, burst up to 2.9 GHz |
| CPU Architecture | 64-bit x86 |
| Graphic Processors | Intel® UHD Graphics |
| Floating Point Unit |  |
| Encryption Engine | (AES-NI) |
| Hardware-accelerated Transcoding | |
| System Memory | 8 GB DDR4, not expandable |
| Maximum Memory | 8 GB DDR4, not expandable |
| Flash Memory | 4GB (Dual boot OS protection) |
| M.2 Slot | 4 x M.2 2280 NVMe Gen3 x2 slots
The system is shipped without SSD.
For the SSD compatibility list, please visit https://www.qnap.com/compatibility/ |
| SSD Cache Acceleration Support | |
| 2.5 Gigabit Ethernet Port (2.5G/1G/100M) | 2 (2.5G/1G/100M/10M) |
| Wake on LAN (WOL) | |
| Jumbo Frame | |
| USB 2.0 port | 3 |
| USB 3.2 Gen 1 port | 2 |
| IR Sensor | (RM-IR004) |
| HDMI™ Output | 2, HDMI™ (up to 2.0 resolution 3840 x 2160 @ 60Hz) |
| Form Factor | Set-top design |
| LED Indicators | SSD1-4 |
| Buttons | Power, Reset, Copy |
| Dimensions (HxWxD) | 30 × 230 × 165 mm |
| Weight (Net) | 1.4 kg |
| Weight (Gross) | 1.7 kg |
| Operating Temperature | 0 - 40 °C (32°F - 104°F) |
| Storage Temperature | -20 - 70°C (-4°F - 158°F) |
| Relative Humidity | 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
| Power Supply Unit | 65W adapter (12VDC), 100-240VAC |
| Power Consumption: HDD Sleep Mode | 18 W |
| Power Consumption: Operating Mode, Typical | 28 W
Tested with drives fully populated.
|
| Fan | 1 x system fan |
| System Warning | Buzzer |
| Kensington Security Slot | yes |
| Standard Warranty | 2 |
| Max. Number of Concurrent Connections (CIFS) - with Max. Memory | 1500 |
