The Synology ActiveProtect appliance DP7400 is a data protection solution that comes predefined hardware (HDDs and SSDs to be installed) that runs ActiveProtect Manager, an operating system designed specifically for backup purposes. With its ability to perform backups, restore, deduplicate, replicate, and manage while ensuring security, the DP7400 is an ideal core management server for your company headquarters. It seamlessly integrates all current and future workloads across multiple sites into clusters, enabling centralized management through a single platform. With immutability, air-gapped backups, and access control, the DP7400 protects against ransomware attacks, and secures all your data.
Specification
| General Specifications | |
| Suggested Backup Source | 83.5 TB¹ |
| Suggested Built-in Restored VM | 9² |
| Cluster Role | Can function as a cluster controller or a managed server in a cluster that supports up to 2,500 servers or 150,000 workloads³ |
| Hardware Specifications | |
| Form Factor | 2U (RU) |
| CPU | AMD EPYC 7272 (12 cores) |
| Memory | 64 GB (Max. 512 GB) |
| Storage Configuration | • 10 x 20 TB HDD (RAID 6 + 1 Spare) • 2 x 3840G SSD (RAID 1) |
| Network Interface | • 1 x 1GbE RJ-45 Port (Management) • 2 x 10GbE RJ-45 Port (Data transfer) (Optional) 2 x 10GbE RJ-45 / 25GbE SFP28 (Data transfer) |
| Dimensions (HxWxD) | • 88 x 430.5 x 692 mm • 88 x 482 x 724 mm (with server handles) |
| Weight | 23.4 kg |
| Power | |
| AC Input Power Voltage | 100 V to 240 V AC |
| Power Frequency | 50/60 Hz, single phase |
| Power Consumption | 163.17 Watt (Access) |
| British Thermal Unit | 556.91 BTU/hr (Access) |
| Operating Environment | Temperature: 32°F to 95°F (0°C to 35°C) Relative humidity: 8% to 80% RH |
| Storage Environment | Temperature: -5°F to 140°F (-20°C to 60°C) Relative humidity: 5% to 95% RH |
| Environment and Packaging | |
| Certification | FCC, CE, UKCA, BSMI, RCM, NCC, VCCI, KC, BIS, EAC |
| Environmental Safety | RoHS compliant |
| Package Contents | • 1 x DP7400 main unit • 10 x 3.5” SATA HDD • 2 x 2.5” SATA SSD • 2 x C13 to C14 Power Cord • 1 x Front Cover • 1 x Accessory Pack • 1 x Quick Installation Guide |
| Warranty | 5 years⁴ |
