Flexible and economic solution for 10GbE adoption
Equipped with an RJ-45 connector and supports IEEE 802.3an/bz (10GBASE-T/NBASE-T) and 802.3x, E10G18-T1 helps you smoothly migrate to a 10GbE networking environment with your existing infrastructure. Supporting backward compatibility and auto-negotiation between 10Gbps, 5Gbps, 2.5Gbps, 1Gbps, and 100Mbps, E10G18-T1 is an economic solution to overcome the data transmission bottleneck for small businesses and home users.
Specification
|
Hardware Specifications
|
||
|---|---|---|
|
General
|
Host Bus Interface | PCIe 3.0 x4 |
| Bracket Height | Low Profile and Full Height | |
| Size (Height x Width x Depth) | 68.1 mm x 86.0 mm x 13.6 mm | |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) | |
| Storage Temperature | -20°C to 60°C (-5°F to 140°F) | |
| Relative Humidity | 5% to 95% RH | |
| Warranty | 5 Years | |
| Notes | The warranty period starts from the purchase date as stated on your purchase receipt. | |
|
Network
|
IEEE Specification Compliance |
|
| Data Transfer Rates | 10 Gbps | |
| Network Operation Mode | Full Duplex | |
| Supported Features |
|
|
|
Compatibility
|
||
|
Applied Models
|
|
|
| Notes | DSM version requirement: 6.2-23739-2 onward (or 6.1-15284-2 onward with DSM 6.1) | |
