18-bay Xeon hybrid rackmount NAS
QNAP TS-h1887XU-RP-E2334-16G
A 2U hybrid-storage rackmount NAS supplied with an Intel Xeon E-2334 4-core processor, 16GB ECC DDR4, dual 10GBASE-T and dual 2.5GbE connectivity. The title conflicts on the total bay count and requires confirmation.
Hybrid rackmount storage with one bay-count detail to verify
The QNAP TS-h1887XU-RP-E2334-16G is described with twelve 3.5-inch SATA bays and six 2.5-inch SATA bays, ECC memory, built-in 10GbE and PCIe Gen 4 expansion. However, the product title also contains the standalone value “8” before the same 12-plus-6 bay breakdown. Confirm whether that value is a title error before publishing.
Key features and benefits
Hybrid HDD and SSD architecture
The detailed title and specification table list twelve 3.5-inch bays plus six 2.5-inch bays.
Xeon and ECC platform
The four-core Intel Xeon E-2334 is paired with 16GB ECC DDR4 and a listed maximum of 128GB.
Dual 10GBASE-T and 2.5GbE
Two 10GBASE-T and two 2.5GbE ports are supplied.
Three PCIe Gen 4 slots
The source lists three expansion slots for the supplied networking, QM2 and Fibre Channel card categories.
Business backup and virtualisation
The supplied content includes file servers, virtualisation, VDI, backup and restore, virtual machines and containers.
Bay-count conflict
The title contains both “8” and a 12-plus-6 bay breakdown; the table lists 18 total bays.
Who is the QNAP TS-h1887XU-RP-E2334-16G best for?
A strong choice for
- Business file servers and shared storage
- Virtualisation servers and VDI storage
- Large backup and restoration tasks
- Hybrid HDD and SSD configurations after confirming bay count
- Buyers needing built-in 10GbE and 2.5GbE
Consider another model if you need
- Publishing before confirming the 8-versus-18 bay-count conflict
- A tower rather than rackmount enclosure
- More than 128GB maximum memory
- Built-in M.2 slots without a QM2 adapter
- A system supplied with drives where none are stated
Key specifications
- Processor
- Intel Xeon E-2334, 4-core/8-thread, 3.4GHz up to 4.8GHz
- Memory
- 16GB ECC DDR4 (1 × 16GB); maximum 128GB (4 × 32GB)
- Drive bays
- Conflict: product title includes 8, while its detailed breakdown and table list 18 total: 12 × 3.5-inch SATA + 6 × 2.5-inch SATA
- Drive compatibility
- 3.5-inch SATA HDDs and 2.5-inch SATA SSDs in 3.5-inch bays; 2.5-inch SATA SSDs in 2.5-inch bays
- Networking
- 2 × 10GBASE-T; 2 × 2.5GbE; 25GbE optional via PCIe adapter
- M.2 slots
- Optional via a QM2 PCIe adapter
- PCIe
- 3 slots: 2 × Gen 4 x4 + 1 × Gen 4 x8
- USB
- 4 × Type-A USB 3.2 Gen 2, 10Gbps
- Form factor
- 2U rackmount
- Dimensions
- 88.6 × 432 × 511.2 mm
- Net weight
- 14.87 kg
- Standard warranty
- 5 (unit not stated in supplied source)
Full technical specifications
View all supplied technical specifications
| CPU | Intel® Xeon® E-2334 4C 8T 3.4GHz, up to 4.8GHz |
|---|---|
| CPU Architecture | 64-bit x86 |
| Graphic Processors | Optional via a PCIe adapter |
| Floating Point Unit | Supported |
| Encryption Engine | Supported (AES-NI) |
| System Memory | 16 GB ECC DDR4 (1 x 16 GB) |
| Maximum Memory | 128GB (4 x 32 GB) |
| Memory Slot | 4 x ECC UDIMM DDR4 For dual-DIMM configuration, you must use a pair of identical DDR4 modules. |
| Flash Memory | 5GB (Dual boot OS protection) |
| Drive Bay | 18 (12 x 3.5-inch SATA + 6 x 2.5-inch SATA) |
| Drive Compatibility | 3.5-inch bays: 3.5-inch SATA hard disk drives 2.5-inch SATA solid state drives 2.5-inch bays: 2.5-inch SATA solid state drives |
| Hot-swappable | Supported |
| M.2 Slot | Optional via a QM2 PCIe adapter |
| SSD Cache Acceleration Support | Supported |
| GPU pass-through | Supported |
| 2.5 Gigabit Ethernet Port (2.5G/1G/100M) | 2 (2.5G/1G/100M) |
| 10 Gigabit Ethernet Port | 2 x 10GBASE-T (10G/5G/2.5G/1G/100M) |
| 25 Gigabit Ethernet Port | Optional via a PCIe adapter |
| Wake on LAN (WOL) | Supported |
| PCIe Slot | 3 (2 x Gen4 x4 +1 x Gen 4 x8) Card dimensions for PCIe slot 1:250 x 68.9 x 23.76 mm / 6.70 x 2.71 x 0.94 inches. Card dimensions for PCIe slot 2:250 x 68.9 x 18.76 mm / 6.70 x 2.71 x 0.74 inches. Card dimensions for PCIe slot 3:250 x 68.9 x 18.76 mm / 6.70 x 2.71 x 0.74 inches. Wider cards can be installed if the next PCIe slot will not be used. |
| USB 3.2 Gen 2 (10Gbps) Port | 4 x Type-A USB 3.2 Gen 2 5V/1A 10Gbps |
| HDMI™ Output | Optional via a PCIe adapter |
| Form Factor | 2U Rackmount |
| LED Indicators | Status (Green/Red) LAN (Green) USB (Blue) HDD status (Green/Red) |
| Buttons | Power, Reset |
| Dimensions (HxWxD) | 88.6 × 432 × 511.2 mm |
| Weight (Net) | 14.87 kg |
| Weight (Gross) | 19 kg |
| Operating Temperature | 0 - 40 °C (32°F - 104°F) |
| Storage Temperature | -20 - 70°C (-4°F - 158°F) |
| Relative Humidity | 5~95% RH non-condensing, wet bulb: 27°C (80.6°F) |
| Power Supply Unit | 2 x 550W PSU |
| Power Consumption: HDD Sleep Mode | 118.77 W |
| Power Consumption: Operating Mode, Typical | 148.94 W |
| Fan | 4 x 60mm, 12VDC |
| Standard Warranty | 5 |
| Max. Number of Concurrent Connections (CIFS) - with Max. Memory | 11000 |
Frequently asked questions about the QNAP TS-h1887XU-RP-E2334-16G
What is the QNAP TS-h1887XU-RP-E2334-16G?
It is a 2U hybrid-storage rackmount NAS with a Xeon E-2334 processor, 16GB ECC DDR4, dual 10GBASE-T and dual 2.5GbE connectivity.
How many drive bays does it have?
The source conflicts: the title includes “8”, while the same title detail and technical table list twelve 3.5-inch plus six 2.5-inch bays, or 18 total. Confirm the correct published title.
How much memory is installed?
The table lists 16GB ECC DDR4 as one 16GB module and a maximum of 128GB.
What networking is built in?
Two 10GBASE-T ports and two 2.5GbE ports are listed.
Are M.2 slots built in?
No built-in M.2 slot is listed; M.2 support is described as optional through a QM2 PCIe adapter.
Is the storage hot-swappable?
The supplied table marks hot swapping as supported.
What is the warranty period?
The table gives the value 5 without a unit, so the duration cannot be confirmed.
