The Best NAS 4 Flash
Hard Drives + Flash SSDs = The best of both worlds
- Quad-Core 10 nm Intel Celeron N5105 CPU
- 4x M.2 slots for NVMe SSDs
- 4 GB of DDR4-2933 RAM
- Dual 2.5-Gigabit Ethernet ports
- 3x USB 3.2 Gen 2 at 10 Gbps
- HDMI 2.0b
- Aesthetically pleasing M.2 SSD heat dissipation thermal vents
- Enjoy, download, upload and stream content with 4K transcoding
- Supports Wake on LAN and Wake on WAN
Specification
Hardware Specifications
|
CPU
|
CPU Model |
Intel Celeron N5105 |
|
CPU Architecture |
x64 64-bit |
|
CPU Frequency |
Quad-Core 2.0GHz (burst up 2.90 GHz) |
Memory
|
Memory |
4GB SO-DIMM DDR4
|
|
Memory Module Pre-installed |
4GB (1x 4GB) |
|
Total Memory Slots |
2 |
|
Memory Expandable up to |
16GB (2x 8GB)
|
|
Flash Memory |
8GB eMMC |
Storage
|
Drive Bays |
4 |
|
M.2 Drive Slots |
4 |
|
Compatible Drive Type
|
- 3.5" SATA HDD
- 2.5" SATA HDD
- 2.5" SATA SSD
- M.2 2280 NVMe
|
|
M.2 PCIe Interface
|
PCIe 3.0 x1 |
|
Maximum Drive Bays with |
16 |
|
Supports Hot Swappable Drives
|
|
External Ports
|
Expansion |
3x USB 3.2 Gen 2 (10Gbps) |
|
Network |
2x 2.5 Gigabit Ethernet (2.5G/1G/100M) |
|
Multimedia Output |
1x HDMI 2.0b |
Others
|
System Fan |
1x 120mm |
|
Infrared Receiver |
|
|
Power Supply Unit / Adapter |
90W x1 |
|
Input Power Voltage |
100V to 240V AC |
|
Certification |
FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS, CCC, UKCA |
|
Warranty |
3 Years |
Operation
|
Power Consumption |
38.3W (Operation)
17.7W (Disk Hibernation)
0.81W (Sleep Mode)
|
|
Noise Level |
19.7dB (HDD idle) |
|
Operation Temperature |
0°C~40°C (32°F~104°F) |
|
Storage Temperature |
-20°C~70°C (-4°F~158°F) |
|
Humidity |
5% to 95% RH |
Size and Weight
|
Size |
170(H) x 174(W) x 230(D) mm |
|
Weight |
2.26 kg / 4.98 lb
|
