Switch to incredible speed with Dual Intel 10GbE, M.2 and 2.5GbE!
- Equipped with an Intel Atom C3538 (Denverton) Quad Core processor
- 8GB DDR4- 2133 – 30% faster than DDR3
- Two 10GbE interfaces with up to 20Gbit/s with link aggregation
- Two 2.5GbE interfaces with up to 5Gbit/s with link aggregation
- Supports 10x 3.15" SATA hard drives
- 2x M.2 NVMe SSD ports for fast caching
- MAX:AS6004Ux2
- Thumbscrews for easy M.2 SSD installation
- Supports wake-up function via LAN and WAN
- Powerful and highly efficient cooling design
- Three-year warranty, industry-leading
Specification
Hardware specifications
|
CPU
|
CPU model |
Intel ATOM C3538 |
|
CPU architecture |
x64 64-bit |
|
CPU frequency |
Quad Core 2.1GHz |
memory
|
memory |
8GB SO-DIMM DDR4 |
|
Memory module, pre-installed |
8GB (1x 8GB) |
|
Total memory slots |
2 |
|
Memory expandable up to |
64GB (2x 32GB)
|
|
Flash memory |
4GB eMMC |
memory
|
Drive bays |
10 |
|
M.2 hard drive bays |
2 |
|
Compatible drive type |
- 3.5" SATA HDD
- 2.5" SATA HDD
- 2.5" SATA SSD
- M.2 2280 NVMe
- M.2 2280 SATA 3
- M.2 2260 SATA 3
- M.2 2242 SATA 3
|
|
M.2 PCIe interface
|
PCIe 3.0 x2 |
|
Max. drive bays with expansion unit |
18 |
|
Hot-swap drive
|
|
External ports
|
Expansion |
2x USB 3.2 Gen 1 |
|
network |
- 2x 10 Gigabit Ethernet (10G/1G)
-
2x 2.5 Gigabit Ethernet (2.5G/1G/100M)
|
|
Multimedia output |
N/A |
other
|
System fan |
2x 120mm |
|
LCD panel |
|
|
Power supply/adapter |
250W x1 |
|
Input voltage |
100V to 240V AC |
|
Certification |
FCC, CE, VCCI, BSMI, C-TICK |
|
Warranty (in years) |
3 years |
Operation
|
Power consumption |
76.8W (operation);
41.1W (hard drive sleep);
|
|
Noise level |
22dB (HDD idle) |
|
Operating temperature |
0°C~40°C (32°F~104°F) |
|
Storage temperature |
-20°C~70°C (-4°F~158°F) |
|
moisture |
5% to 95% RH |
Size and weight
|
Size |
215.5(H) x 293(W) x 230(D) mm |
|
Weight |
6.4 (kg) / 14.1 (lb) |
