QNAP TS-h1065eU-8G
The QNAP TS-h1065eU-8G is a 2U short-depth rackmount NAS designed for small and medium-sized businesses and space-constrained installations. Its compact 297.4mm-deep chassis combines eight 3.5-inch SATA drive bays, two rear E1.S/M.2 NVMe PCIe slots, 8GB DDR5 memory, dual 2.5GbE ports and PCIe expansion.
What is the QNAP TS-h1065eU-8G?
The TS-h1065eU-8G is an Intel-powered, 2U short-depth NAS with eight front drive bays and two rear E1.S/M.2 NVMe Gen 3 x1 slots. It runs the QuTS hero operating system and supports flexible storage, networking and expansion configurations within a compact 30cm-class chassis.
Short-Depth Design for Flexible Deployment
A compact rackmount chassis for installations where available depth is limited.
The TS-h1065eU has a chassis depth of 297.4mm, making it suitable for small cabinets and other space-constrained environments. The supplied product information identifies factories, small offices, surveillance rooms, audiovisual rooms and in-vehicle applications as potential deployment environments.
It is compatible with the supplied RAIL-B02 and Rail-S01 short rail kit references.
Flexible Storage and Memory Configuration
Combine SATA storage with rear NVMe slots and expandable DDR5 memory.
Eight SATA Drive Bays
The front drive bays support 3.5-inch SATA hard disk drives and 2.5-inch SATA solid state drives, with hot-swappable operation.
Two E1.S/M.2 NVMe Slots
Two rear E1.S/M.2 NVMe PCIe Gen 3 x1 slots support E1.S NVMe SSDs or M.2 NVMe SSDs and can be configured for SSD caching.
DDR5 Memory
The system includes 8GB SODIMM DDR5 memory and supports up to 16GB through its single SODIMM slot. The supplied description states support for In-Band ECC.
Networking and Expansion
Built-in multi-Gigabit networking with options for higher-speed connectivity.
Dual 2.5GbE Ports
Two 2.5GbE ports support 2.5G, 1G, 100M and 10M speeds. Port Trunking or SMB Multichannel can be used to accelerate data transfer and backup workflows.
E1.S/M.2 Network Module Option
The supplied product information states that the E1.S/M.2 slots can also accommodate the QXG-ES10G1T network module for 10GbE connectivity.
PCIe Gen 3 Expansion
One PCIe Gen 3 x2 slot supports compatible 5GbE or 10GbE network interface cards and QM2 expansion cards.
QuTS hero Data Protection
ZFS-based storage features designed to support data integrity and system stability.
The built-in QuTS hero operating system uses the ZFS file system and provides supplied data protection features including self-healing of static data, WORM, data deduplication and snapshot backups.
AES-NI provides AES 256-bit hardware-accelerated encryption for securing sensitive data while supporting system performance.
Long-Term Availability
Extended product availability and support for planned deployments.
The supplied product information states that the TS-h1065eU will be available and supported by QNAP for an extended period, up to 2031.
It is also listed as receiving the 2026 MSP Today Product of the Year Award for the QuTS hero operating system.
Frequently Asked Questions
Quick answers about the QNAP TS-h1065eU-8G.
How many drive bays does the TS-h1065eU-8G have?
It has eight front 3.5-inch SATA drive bays and two rear E1.S/M.2 NVMe Gen 3 x1 slots.
Which drives are supported?
The 3.5-inch bays support 3.5-inch SATA hard disk drives and 2.5-inch SATA solid state drives. The rear slots support E1.S NVMe SSDs and M.2 NVMe SSDs.
How much memory is installed?
This configuration includes 8GB SODIMM DDR5 memory and supports a maximum of 16GB using one 16GB module.
Does the TS-h1065eU-8G include 10GbE?
It includes two 2.5GbE ports. The supplied information lists optional 10GbE connectivity through a network adaptor, a PCIe expansion card or the QXG-ES10G1T network module installed in an E1.S/M.2 slot.
Which operating system is built in?
The TS-h1065eU-8G includes the QuTS hero operating system, which uses the ZFS file system.
What is the chassis depth?
The chassis measures 297.4mm deep and uses a 2U short-depth rackmount form factor.
What is the standard warranty?
The supplied datasheet lists a standard three-year warranty.
Memory installation note: Use only QNAP memory modules to maintain system performance and stability. Refer to the hardware user manual before installing compatible memory. Unsupported modules may degrade performance, cause errors or prevent the operating system from starting.
Product images are for illustrative purposes only. Designs and specifications are subject to change without notice.
