The Lockerstor 12R Pro Gen2 Bring Rising and Ryzen Speeds!

• Powered by the AMD Ryzen 7 Pro 7745 processor with 8 cores and 16 threads
• Equipped with 16 GB ECC DDR5-4800 memory, expandable up to 192 GB
• Dual 10GbE + Dual Gigabit Ethernet
• Expansion slots: PCIe 5.0 x8 and PCIe 5.0 x4
• Supports PCIe Gen5 SSDs
• Dual redundant 80 PLUS Platinum power supplies
• Supports Wake on LAN on the Gigabit Ethernet ports

Specification

Hardware Specifications
CPU	CPU Model	AMD Ryzen 7 Pro
	CPU Architecture	x64 64-bit
	CPU Frequency	3.8GHz up to 5.3GHz
Memory	Memory	16GB ECC DDR5-4800 UDIMM
	Memory Module Pre-installed	16GB (1x 16GB)
	Total Memory Slots	4
	Memory Expandable up to	192GB (4x 48GB)  Support mixed capacity
	Flash Memory	32GB SATA DOM
Storage	Drive Bays	12
	M.2 Drive Slots	1
	Compatible Drive Type	3.5" SATA HDD 2.5" SATA HDD 2.5" SATA SSD M.2 2280 NVMe
	M.2 PCIe Interface	PCIe 5.0 x4
	Maximum Drive Bays with	36
	Supports Hot Swappable Drives
External Ports	Expansion	4x USB 3.2 Gen 1 Type-A
	Network	2 x Gigabit Ethernet (1G/100M, WOL) 2 x 10Gigabit Ethernet (10G/1G)
	PCIe Expansion Slots	1 x Gen5 x8 slot (x8 link); 1 x Gen5 x4 slot (x4 link) for optional 10/25/40/50 GbE card and SAS card
	Multimedia Output	HDMI x1 (for service only)
Others	System Fan	3x 60mm
	Power Supply Unit / Adapter	550W x2
	Input Power Voltage	100V to 240V AC
	Redundant power supply
	Service LED Indicator
	Certification	FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS, UKCA
	Warranty	5 Years
Operation	Power Consumption	102W (Operation); 99W (Disk Hibernation);
	Noise Level	N/A
	Operation Temperature	0°C~40°C (32°F~104°F)
	Storage Temperature	-20°C~70°C (-4°F~158°F)
	Humidity	5% to 95% RH
Size and Weight	Size	88(H) x 439(W) x 576(D) mm
	Weight	14 kg / 30.9lb
