High-performance mass storage
The 12-bay Synology DS3622xs+ is a powerhouse NAS capable of fitting into small and medium business environments with intensive and multi-user workloads. Its high capacity, scalability, and processing power make it ideal for VM and container storage, for lightning-fast file sharing, and as a network video recorder for large surveillance deployments. It comes with powerful storage management, file syncing, surveillance, and backup software, and is suitable for editing high-quality video.
CPU
Six-core Intel® Xeon® processor
Memory
16 GB DDR4 ECC, expandable to 48 GB
Scalability
Expand to 36 drives
Specification
|
Hardware Specifications
|
||
|---|---|---|
|
CPU
|
CPU Model | Intel Xeon D-1531 |
| CPU Quantity | 1 | |
| CPU Core | 6 | |
| CPU Architecture | 64-bit | |
| CPU Frequency | 2.2 (base) / 2.7 (turbo) GHz | |
| Hardware Encryption Engine |
|
|
|
Memory
|
System Memory | 16 GB DDR4 ECC SODIMM |
| Memory Module Pre-installed | 16 GB (8 GB x 2) | |
| Total Memory Slots | 4 | |
| Maximum Memory Capacity | 48 GB (8 GB x 2 + 16 GB x 2) | |
| Notes |
|
|
|
Storage
|
Drive Bays | 12 |
| Maximum Drive Bays with Expansion Unit | 36 (DX1222 x 2) | |
| Drive Type |
|
|
| Hot Swappable Drive* |
|
|
| Notes | The use of non-validated components may limit certain functionality and result in data loss and system instability. | |
|
External Ports
|
RJ-45 1GbE LAN Port | 2 |
| RJ-45 10GbE LAN Port | 2 | |
| Out-of-Band Management LAN Port | 1 | |
| USB 3.2 Gen 1 Port* | 2 | |
| Expansion Port | 2 | |
| Expansion Port Type | Mini-SAS HD | |
| Notes |
|
|
|
PCIe
|
PCIe Expansion | 1 x Gen3 x8 slot (x8 link) |
|
Appearance
|
Size (Height x Width x Depth) | 270 mm x 300 mm x 340 mm |
| Weight | 9.8 kg | |
|
Others
|
System Fan | 120 mm x 120 mm x 2 pcs |
| Fan Speed Mode |
|
|
| Easy Replacement System Fan |
|
|
| Power Recovery |
|
|
| Noise Level* | 25 dB(A) | |
| Scheduled Power On / Off |
|
|
| Wake on LAN / WAN |
|
|
| Power Supply Unit / Adapter | 550 watts | |
| AC Input Power Voltage | 100V to 240V AC | |
| Power Frequency | 50/60 Hz, Single Phase | |
| Power Consumption | 94.42 watts (Access) 54.33 watts (HDD Hibernation) |
|
| British Thermal Unit | 322.39 BTU/hr (Access) 185.51 BTU/hr (HDD Hibernation) |
|
| Notes |
|
|
|
Temperature
|
Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Storage Temperature | -20°C to 60°C (-5°F to 140°F) | |
| Relative Humidity | 5% to 95% RH | |
|
Certification
|
|
|
|
Warranty
|
5 Years | |
| Notes | The warranty period starts from the purchase date as stated on your purchase receipt. | |
|
Environment
|
RoHS Compliant | |
|
Packaging Content
|
|
|
