Ryzen up to the challenge!
- Quad-Core AMD Ryzen Embedded V3C14 CPU @ 2.3 GHz - 3.8 GHz Turbo
- 16GB of server-grade DDR5-4800 ECC memory (Max 64GB)
- Quad M.2 slots for NVMe SSDs – Doubled Performance with PCIe 4.0
- 2x USB4 ports at 40 Gbps
- 3x USB 3.2 Gen 2 Type-A at 10 Gbps
- 2x 10-Gigabit Ethernet
- 2x 5-Gigabit Ethernet
- Supports Wake on LAN and Wake on WAN (5 GbE)
Specification
Hardware Specifications
|
CPU
|
CPU Model |
AMD Ryzen V3C14 |
|
CPU Architecture |
x64 64-bit |
|
CPU Frequency |
Quad-Core 2.3GHz (burst up 3.8 GHz) |
Memory
|
Memory |
16GB ECC DDR5-4800 SO-DIMM
|
|
Memory Module Pre-installed |
16GB (1x 16GB) |
|
Total Memory Slots |
2 |
|
Memory Expandable up to |
64GB
- Support mixed capacity
- Supports ECC memory
- ECC functionality will be disabled if non-ECC memory is installed or mixed with ECC memory
|
|
Flash Memory |
8GB eMMC |
Storage
|
Drive Bays |
10 |
|
M.2 Drive Slots |
4 |
|
Compatible Drive Type
|
- 3.5" SATA HDD
- 2.5" SATA HDD
- 2.5" SATA SSD
- M.2 2280 NVMe
|
|
M.2 PCIe Interface
|
PCIe 4.0 x1 |
|
Maximum Drive Bays with expansion unit
|
22 |
|
Supports Hot Swappable Drives
|
|
External Ports
|
Expansion |
- 3 x USB 3.2 Gen 2 ( 10Gbps ) Type-A
- 2 x USB 4.0 (40Gbps) Type-C
- Note. USB 4.0 is backward compatible with 3.2 Gen2 (10Gbps max), USB 3.2 Gen1 (5Gbps) and 2.0
- Note. The Lockerstor Gen3 and Flashstor Gen2 series are based on AMD's current USB4 driver. AMD USB4 at the moment only supports external storage devices and direct connection between another Lockerstor Gen3 or Flashstor Gen2 series NAS.
|
|
Network |
- 2x 5 Gigabit Ethernet (5G/2.5G/1G/100M)
- 2x 10 Gigabit Ethernet (10G/2.5G/1G/100M)
|
|
PCIe Expansion Slots |
PCIe 4.0, x4 link, (for optional 10 GbE card)
|
|
Multimedia Output |
N/A |
Others
|
System Fan |
2x 120mm |
|
LCD Panel |
|
|
Power Supply Unit / Adapter |
250W x1 |
|
Input Power Voltage |
100V to 240V AC |
|
Certification |
FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS, CCC, UKCA |
|
Warranty |
3 Years |
Operation
|
Power Consumption |
68 W (Operation);
2.4 W (Sleep Mode)
|
|
Noise Level |
22dB (HDD idle) |
|
Operation Temperature |
0°C~40°C (32°F~104°F) |
|
Storage Temperature |
-20°C~70°C (-4°F~158°F) |
|
Humidity |
5% to 95% RH |
Size and Weight
|
Size |
215.5(H) x 293(W) x 230(D) mm |
|
Weight |
6.55 kg / 14.44 lb
|
