6-Bay 10GbE Tower NAS
QNAP TS-632X-4G 10GbE NAS
A six-bay tower NAS with an Alpine AL524 quad-core processor, 4 GB DDR4 memory, dual 10GbE SFP+, dual 2.5GbE and a PCIe Gen 3 x4 expansion slot.
Six-bay storage with dual-port 10GbE SFP+
The QNAP TS-632X-4G combines six SATA bays with two 10GbE SFP+ and two 2.5GbE ports for backup, rapid data transfer and shared storage. A PCIe Gen 3 x4 slot, ECC-memory support, Docker container support, snapshots and USB One Touch Copy provide practical options for growing business workflows.
Key features and benefits
Dual 10GbE SFP+
Two 10GbE SFP+ ports support high-bandwidth transfers and shorter backup windows.
Dual 2.5GbE RJ45
Two multi-gigabit copper ports support SMB Multichannel or port-trunking configurations.
Expandable memory
The system includes 4 GB DDR4 and supports a stated maximum of 16 GB, including ECC-memory support.
PCIe Gen 3 x4
One PCIe slot can add compatible networking or M.2 SSD functionality.
Backup and snapshots
Centralised backup and scheduled snapshots support recovery planning and ransomware resilience.
Container applications
Docker container support enables additional services to run on the NAS.
Who is this model best for?
A strong choice for
- 10GbE SFP+ file sharing
- Six-bay backup storage
- Containerised applications
- Teams needing both SFP+ and 2.5GbE
- Sites planning PCIe-based expansion
Consider another model if you need
- You require built-in M.2 slots
- You need an x86 processor platform
- You require integrated graphics or HDMI
Key specifications
- Processor
- AnnapurnaLabs Alpine AL524, 4-core 2.0 GHz
- System memory
- 4 GB SODIMM DDR4 (1 × 4 GB)
- Maximum memory
- 16 GB (1 × 16 GB)
- Drive bays
- 6 × 3.5-inch SATA 6Gb/s, 3Gb/s
- Drive compatibility
- 3.5-inch SATA HDD; 2.5-inch SATA HDD; 2.5-inch SATA SSD
- Networking
- 2 × 10GbE SFP+; 2 × 2.5GbE RJ45
- Expansion
- 1 × PCIe Gen 3 x4 slot
- USB
- 2 × USB 3.2 Gen 1
- Dimensions
- 226.5 × 235 × 165 mm
- Power supply
- 120W adapter, 100–240VAC
Full technical specifications
Processor, memory and storage
| CPU | AnnapurnaLabs, an Amazon company Alpine AL524, 4-core, 2.0GHz |
|---|---|
| CPU Architecture | 64-bit ARM |
| Floating Point Unit | Supported |
| Encryption Engine | Supported |
| System Memory | 4 GB SODIMM DDR4 (1 x 4 GB) |
| Maximum Memory | 16 GB (1 x 16 GB) |
| Memory Slot | 1 x SODIMM DDR4 Support ECC memory |
| Flash Memory | 512 MB (Dual boot OS protection) |
| Drive Bay | 6 x 3.5-inch SATA 6Gb/s, 3Gb/s |
| Drive Compatibility | 3.5-inch bays: 3.5-inch SATA hard disk drives 2.5-inch SATA hard disk drives 2.5-inch SATA solid state drives |
| Hot-swappable | Supported |
| SSD Cache Acceleration Support | Supported |
Network, ports and expansion
| 2.5 Gigabit Ethernet Port (2.5G/1G/100M) | 2(2.5G/1G/100M) |
|---|---|
| 10 Gigabit Ethernet Port | 2 x 10GbE SFP+ |
| Wake on LAN (WOL) | Supported |
| Jumbo Frame | Supported |
| PCIe Slot | 1 Slot 1: PCIe Gen 3 x4 Card dimensions for PCIe slot:190 x 68.9x 18.76 mm / 7.48 x 2.71 x 0.74 inches. |
| USB 3.2 Gen 1 port | 2 |
Physical, environmental and power
| Form Factor | Tower |
|---|---|
| LED Indicators | Power, Status, LAN, USB, HDD1-6 |
| Buttons | Power, Reset, USB Auto Copy |
| Dimensions (HxWxD) | 226.5 × 235 × 165 mm |
| Weight (Net) | 2.5 kg |
| Weight (Gross) | 4.96 kg |
| Operating Temperature | 0 - 40 °C (32°F - 104°F) |
| Storage Temperature | -20 - 70°C (-4°F - 158°F) |
| Relative Humidity | 5-95% RH non-condensing, wet bulb: 27°C (80.6°F) |
| Power Supply Unit | 120W adapter (12VDC), 100-240VAC |
| Fan | 2 x 90mm, 12VDC |
| System Warning | Buzzer |
| Kensington Security Slot | Supported |
Frequently asked questions about the TS-632X-4G
What is the QNAP TS-632X-4G?
It is a six-bay tower NAS with dual 10GbE SFP+, dual 2.5GbE and one PCIe Gen 3 x4 expansion slot.
Which processor does the TS-632X-4G use?
The TS-632X-4G uses an AnnapurnaLabs Alpine AL524 four-core 2.0 GHz processor.
How much memory is included with the TS-632X-4G?
The TS-632X-4G includes 4 GB SODIMM DDR4 memory and supports a stated maximum of 16 GB, with ECC-memory support listed.
How many drive bays does the TS-632X-4G have?
It has six 3.5-inch SATA 6Gb/s, 3Gb/s drive bays.
Which drive types are supported by the TS-632X-4G?
It supports 3.5-inch SATA HDDs, 2.5-inch SATA HDDs and 2.5-inch SATA SSDs.
Which network ports are built into the TS-632X-4G?
It includes two 10GbE SFP+ ports and two 2.5GbE RJ45 ports.
What expansion options does the TS-632X-4G provide?
It has one PCIe Gen 3 x4 slot for compatible expansion cards.
What form factor is the TS-632X-4G?
It is a desktop tower NAS.
What are the dimensions of the TS-632X-4G?
Its stated dimensions are 226.5 × 235 × 165 mm.
Does the TS-632X-4G support container applications?
Yes. Docker container support is included in the stated feature set.
Important information
Check drive, memory and PCIe-card compatibility before purchase.
