4-bay fanless industrial NAS
QNAP TS-i410X-8G
A fanless industrial NAS supplied with an Intel Atom x6425E 4-core processor, fixed 8GB onboard memory, four 2.5-inch SATA SSD bays, dual 10GBASE-T and an operating range of -40°C to 70°C.
Fanless industrial storage for harsh operating environments
The QNAP TS-i410X-8G is an industrial-grade, fanless 4-bay NAS designed for factories, warehouses, transportation and other rugged environments. The supplied configuration combines an Intel Atom x6425E processor, fixed 8GB memory, four SATA SSD bays, dual 10GBASE-T and wide-range power input, with availability stated through 2029.
Key features and benefits
Rugged fanless construction
The supplied description highlights a fanless design, solid chassis and operation from -40°C to 70°C.
Dual 10GBASE-T networking
Two multi-speed 10GBASE-T ports are listed for high-speed backup, file sharing, virtualisation and video transmission.
SSD-only drive design
Four 2.5-inch SATA bays are specified for 2.5-inch SATA solid-state drives.
Fixed onboard memory
The supplied configuration includes 8GB onboard memory that is explicitly marked non-expandable.
4K HDMI capability
HDMI 1.4b output up to 3840 × 2160 at 30Hz, 4K playback and real-time transcoding are listed.
Long-term availability
The original product description states long-term availability up to the year 2029.
Who is the QNAP TS-i410X-8G best for?
A strong choice for
- Factories and warehouses
- Transportation and rugged deployments
- Fanless industrial installations
- SSD-based storage over dual 10GbE
- Virtual machines and containers
- Long-lifecycle projects requiring availability through 2029
Consider another model if you need
- Expandable system memory
- 3.5-inch hard-drive support
- More than 4 internal drive bays
- Operating temperatures outside the supplied range
- A standard office-focused NAS enclosure
Key specifications
- Processor
- Intel Atom x6425E 4-core / 4-thread processor, burst up to 3.0GHz
- Graphics
- Intel UHD Graphics for 10th Gen Intel processors
- Memory
- 8GB onboard, non-expandable; some RAM is reserved as shared graphics memory
- Drive bays
- 4 × 2.5-inch SATA 6Gb/s, 3Gb/s; system shipped without HDD
- Drive compatibility
- 2.5-inch SATA solid-state drives
- Networking
- 2 × 10GBASE-T (10G/5G/2.5G/1G)
- USB
- 4 × USB 3.2 Gen 2
- HDMI
- 1 × HDMI 1.4b, up to 3840 × 2160 at 30Hz
- Operating temperature
- -40°C to 70°C (-40°F to 158°F)
- Power inputs
- External power adapter, 90W and above, AC 100–240V; or 9–36V DC input
- Dimensions
- 62 × 180 × 244 mm
- Net weight
- 3.1 kg
- Standard warranty
- 3 (unit not stated in supplied source)
Full technical specifications
View all supplied technical specifications
| CPU | Intel® Atom® x6425E 4-core/4-thread processor, burst up to 3.0 GHz |
|---|---|
| CPU Architecture | 64-bit x86 |
| Graphic Processors | Intel® UHD Graphics for 10th Gen Intel® Processors |
| Floating Point Unit | Supported |
| Encryption Engine | Supported (AES-NI) |
| Hardware-accelerated Transcoding | Supported |
| System Memory | 8 GB on board (non-expandable) Note: Reserves some RAM for use as shared graphics memory. |
| Maximum Memory | 8 GB on board (non-expandable) |
| Flash Memory | 4GB (Dual boot OS protection) |
| Drive Bay | 4 x 2.5-inch SATA 6Gb/s, 3Gb/s The system is shipped without HDD. |
| Drive Compatibility | 2.5-inch SATA solid state drives |
| Hot-swappable | Supported |
| SSD Cache Acceleration Support | Supported |
| 10 Gigabit Ethernet Port | 2 x 10GBASE-T (10G/5G/2.5G/1G) |
| Wake on LAN (WOL) | Supported |
| Jumbo Frame | Supported |
| USB 3.2 Gen 2 (10Gbps) Port | 4 |
| HDMI™ Output | 1, HDMI™ 1.4b (up to 3840 x 2160 @ 30Hz) |
| Form Factor | Tower |
| LED Indicators | Power/Status, LAN, SSD 1-4 |
| Buttons | Power, Reset |
| Dimensions (HxWxD) | 62 × 180 × 244 mm Dimensions do not include foot pad (foot pad may be up to 30mm / 1.18 inches high depending on model) |
| Weight (Net) | 3.1 kg |
| Weight (Gross) | 3.1 kg |
| Operating Temperature | -40 - 70 °C (-40°F - 158°F) |
| Storage Temperature | -45 - 85°C (-49°F - 185°F) |
| Relative Humidity | 5-95% RH non-condensing, wet bulb: 27°C (80.6˚F) |
| Power Supply Unit | 1. External Power Adapter, 90W and above, AC 100-240V 2. 9-36V DC input To avoid potential personal injury or component damage, DO NOT plug in two power inputs simultaneously. |
| Power Consumption: HDD Sleep Mode | 17.628 W |
| Power Consumption: Operating Mode, Typical | 25.592 W Tested with drives fully populated. |
| System Warning | Buzzer |
| Kensington Security Slot | Supported |
| Standard Warranty | 3 |
| Max. Number of Concurrent Connections (CIFS) - with Max. Memory | 1500 |
Frequently asked questions about the QNAP TS-i410X-8G
What is the QNAP TS-i410X-8G?
It is a fanless industrial NAS with four 2.5-inch SATA SSD bays, an Intel Atom x6425E processor, fixed 8GB memory and two 10GBASE-T ports.
Can the memory be expanded?
No. The supplied specification states that the 8GB onboard memory is non-expandable.
Which drives are supported by the supplied specification?
The source lists 2.5-inch SATA solid-state drives. It also states that the system is shipped without an HDD.
What temperature range is listed?
The supplied operating range is -40°C to 70°C, with a storage range of -45°C to 85°C.
Can both power inputs be connected at the same time?
No. The supplied warning says not to plug in both power inputs simultaneously because this may cause personal injury or component damage.
How long is the model stated to be available?
The supplied product description states long-term availability up to the year 2029.
What is the warranty period?
The source provides the value 3 without a unit, so the warranty duration cannot be confirmed.
